W01 V2.0 Inductance Tester Motherboard Coil Tester

The W01 V2.0 Inductance Tester Motherboard Coil Tester is a compact diagnostic PCB designed to facilitate inspection and evaluation of coils, inductors and related winding components. Intended as a test platform or replacement motherboard within coil-testing fixtures, this unit provides a stable, serviceable base for technicians and hobbyists performing routine measurements, maintenance, or component verification.Engineered for straightforward integration into existing test setups, the board exposes common connection points and clearly labeled test pads to simplify wiring and probe access. Its layout groups key nodes logically to speed troubleshooting and to reduce the need for temporary adapters during bench work. Mounting holes and durable solder points allow secure installation in fixtures and enclosures while preserving the ability to rework or replace the board when required.Operation is uncomplicated: connect the component under test to the corresponding terminals, apply the measurement method or instrument of your choice, and observe the resulting values. The W01 V2.0 is suitable for use with standard LCR meters, impedance analyzers, and dedicated inductance testers where a dedicated motherboard or fixture is required. As a passive test carrier, the board does not alter active measurement behavior but provides a convenient, low‑impedance interface between the device under test and measurement equipment.Care and handling are straightforward: keep the board clean, avoid excessive mechanical stress to solder joints and connectors, and store in a static‑safe environment when not in use. This product is provided as a functional replacement or development aid for coil and inductor testing workflows and is compatible with common bench testing practices.
