The PIC K150 Microcontroller USB Programmer is a compact programmer supporting a wide range of PIC microcontrollers. It is intended for flashing and development tasks with numerous PIC families listed below.
Supported PICs (selected list):
12C508, 12C508A, 12C509, 12C509A, 12C671, 12C672, 12CE673, 12CE674, 12F629, 12F675.
16C505, 16C554, 16C558, 16C61, 16C62, 16C62A, 16C62B, 16C63, 16C63A, 16C64, 16C64A, 16C65, 16C65A, 16C65B, 16C66, 16C66A, 16C67, 16C71, 16C71A, 16C72, 16C72A, 16C73, 16C73A, 16C73B, 16C74, 16C74A, 16C74B, 16C76, 16C77, 16C83, 16C83A, 16C620, 16C620A, 16C621, 16C621A, 16C622, 16C622A, 16C63A, 16C716, 16C711, 16C712, 16C710, 16C773, 16C774, 16C745, 16C765, 16C773, 16C774, 16C716, 16C765.
16F73, 16F74, 16F76, 16F77, 16F77A, 16F83, 16F84, 16F84A, 16F87, 16F88, 16F627, 16F627A, 16F628, 16F628A, 16F630, 16F648A, 16F676, 16F684, 16F688, 16F737, 16F747, 16F767, 16F777, 16F818, 16F819, 16F870, 16F871, 16F872, 16F873, 16F873A, 16F874, 16F874A, 16F876, 16F876A, 16F5x, 10Fxxx.
18F242, 18F248, 18F252, 18F258, 18F422, 18F448, 18F452, 18F458, 18F1220, 18F1320, 18F2220, 18F2320, 18F4220, 18F4320, 18F442, 18F448, 18F452, 18F458, 18F6525, 6621, 8525, 8621 (listed as added).
Entries added from community packs include diypack23 additions such as 16C63A, 16C74, 16F684, 16F874 and others, plus diypack25 addition 12F683. Support for 16F88 was added in diypack22.
This product description lists supported device identifiers as provided; consult supplied documentation or support resources for detailed wiring and programming procedures.
