ULN 2803

The ULN 2803 is a high-voltage, high-current Darlington transistor array designed to drive loads that require significant power. It translates low-level logic inputs into robust, sink-capable outputs suitable for inductive and resistive loads, making it a practical choice for relay, motor, and lamp control. Eight Darlington pairs, each capable of sinking up to 500mA Maximum collector-emitter voltage of 50V Integrated clamp (flyback) diodes for protection of inductive loads Compact 18-pin DIP package for easy PCB integration Low input current requirement (as low as 1.35mA) for minimal control power Designed to improve reliability and reduce external component count, the ULN 2803 combines amplification and protection in a single device. The Darlington configuration amplifies input signals so that low-voltage logic can drive medium- to high-current loads without additional driver stages. Built-in clamp diodes protect against voltage spikes caused by switching inductive loads, enhancing device longevity and simplifying circuit design. This device is well suited to industrial automation, robotics, and embedded control systems where efficient power handling, protection, and compact integration are required. Its design reduces circuit complexity while providing dependable switching performance for a wide range of applications.
